[英語版]IPC-D-356B: Bare Substrate Electrical Test Data Format

データ 英語

商品説明

『ベアボード電気テストデータフォーマット』

※ シングルユーザーライセンス(データ、英語)版となります。日本語版は未出版です。
※ ご購入と同時にIPCのユーザーライセンス規約に同意したものとみなされます。画像にあるライセンス規約を予めご確認下さい。
※ ダウンロードと同時に透明タグによる個別IDがPDFファイルに紐付き、印刷及び配布・共有はできません。

【DESCRIPTION】
This standard describes a data format for transmitting bare board electrical test information in digital form, including data suitable for computer-aided repair. When used as a netlist input to test data processing, the receiver of IPC-D-356B data will determine test point assignments and positioning. Enhancements to the B Revision include updates to the concept of testable areas to account for SMD pads and unusually shaped pads, updating of complex records for representing all inter-layer connections in nets, a simple polygon description format that improves graphical representation of the bare board, and new methods for indentifying endpoints and midpoints.

この規格は、コンピュータ支援修理に適したデータを含む、ベアボード電気試験情報をデジタル形式で伝送するためのデータフォーマットを記述している。 テストデータ処理へのネットリスト入力として使用されるとき、IPC-D-356Bデータの受信者はテストポイントの割り当てと位置を決定する。改訂により、SMDパッドと異形パッドを考慮したテスト可能領域の概念の更新、すべての層間接続をネットで表すための複雑なレコードの更新、ベアボードのグラフィカル表現を改善する単純なポリゴン記述形式の更新、エンドポイントとミッドポイント識別の新しい方法が追加された。

(リビジョンB,2022年発行,33頁,英語)

¥ 38,500(税込)
