[英語版]IPC-2152: Standard for Determining Current Carrying Capacity in Printed Board Design

データ 英語

商品説明

『プリント基板設計における電流容量の決定基準』

※ シングルユーザーライセンス(データ、英語)版となります。日本語版は未出版です。
※ ご購入と同時にIPCのユーザーライセンス規約に同意したものとみなされます。画像にあるライセンス規約を予めご確認下さい。
※ ダウンロードと同時に透明タグによる個別IDがPDFファイルに紐付き、印刷及び配布・共有はできません。

【DESCRIPTION】
The sole industry standard for determining appropriate internal and external conductor sizes on printed boards as a function of the current carrying capacity required and the acceptable conductor temperature rise. This document provides guidance on how thermal conductivity, vias, copper planes, power dissipation and printed board material and thickness all factor into the relationship between current, conductor size, and temperature.

本書は、必要な電流容量があり、かつ温度上昇が許容可能な範囲である、プリント基板上の内部/外部導体の適切なサイズを決定するための唯一の業界基準である。熱伝導率及びビア、銅箔面、消費電力、プリント基板の材料及び厚さのすべてが、電流及び導体のサイズ、温度との関係にどのような影響を及ぼすかについてのガイダンスを提供している。

(初版,2009年発行,97頁,英語)

¥ 49,500(税込)
